General
Function
Copy, print, scan, optional: fax
Print technology
Laser colour and b/w
Original format
max A3 from platen glass
Copy speed
max 25 A4 pages/min and max 12 A3 pages/min in colour and b/w
1st page
Colour: 8.5/9.2 seconds*, b/w: 6.4/7.0 seconds*
Copy resolution
600 x 600 dpi
Paper feed
2 x 500 sheet universal cassettes (cassette 1: A6R-A4, cassette 2: A6R-SRA3 [320 x 450 mm]), 150 sheet multi-bypass (A6R-SRA3, Banner [305 x 1,219 mm]), SRA3 and banner only for printing
Paper weights
Universal cassette 52-300 g/m², multi-bypass 52-300 g/m², duplex 64-256 g/m²
Paper output
500 sheet A4
System memory
4 GB RAM, 32 GB SSD/optional: 320 GB HDD**
Continuous copying
1-9,999 copies
Zoom
25 %-400 % in steps of 1 %
Functions
Adjustable colour touch screen (10.1 inch), duplex, 1,000 management codes, skip blank pages, motion sensor etc.
Dimensions / Weight
Dimensions
790 x 602 x 665 mm (H x W x D)
Environment
Mains voltage
220/240 V, 50/60 Hz
Power consumption
approx. 1,750 W max, approx. 455 W in operation, approx. 50 W in stand-by mode, approx. 0.7 W in sleep mode, TEC value: 1.059 KWh/week
Safety
GS/TÜV, CE, Trusted Platform Module (TPM)
Print system
Type
Integrated within the system
Print resolution
600 x 600 dpi, max 1,200 x 1,200 dpi
Processor
Freescale QorIQ T1024 (Dual Core) 1.0 GHz
Interfaces
USB 3.0, USB 2.0, 10/100/1000Base-TX, USB host, NFC
Network protocols
TCP/IP, Net BEUI
Operating systems
Windows 7/8.1/10, Server 2008/2008 R2/2012/2012 R2/2016, Novell NetWare***, Linux, Mac ex OS 10.9
Emulations
PCL6 (5e, XL), KPDL 3 (PostScript 3 compatible), XPS, PDF 1.7, PRESCRIBE IIc
Functions
Colour Optimiser, USB direct printing, PDF/XPS direct printing, printing of e-mails, private printing, barcode printing, Mobile Print (Android/iOS)/ Apple AirPrint, Google Cloud Print
Scan system
Scan type
CCD colour and b/w
Scan speed
max 100 (simplex) or 180 (duplex) A4 originals/min in colour and b/w with DP-7130 (300 dpi)
Scan resolution
200 dpi, 300 dpi, 400 dpi, 600 dpi
Scan mode
Photo, text, photo/text, optimised for OCR
File types
TIFF, PDF, PDF/A, high compression PDF, encrypted PDF, JPEG, XPS, Open XPS
Interfaces
10/100/1000BaseTX
Operating systems
Windows 7/8.1/10, Server 2008/2008 R2/2012/2012 R2/2016
Functions
Scan to SMB, scan to e-mail, scan to FTP, scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP
Fax system
Type
optional Faxsystem 12
Transmission speed
3 seconds or less using JBIG
Compression method
JBIG, MMR, MR, MH
Fax resolution
Standard (200 x 100 dpi), fine (200 x 200 dpi), super fine (200 x 400 dpi), ultra fine (400 x 400 dpi), 600 x 600 dpi
Abbreviated dial
2,000 numbers
One-touch dial
1,000 numbers
Operating systems
Windows 7/8.1/10, Server 2008/2008 R2/2012/2012 R2/2016
Functions
Network fax driver, automatic redialling, delayed transmission, max 2 fax kits for parallel transmission and reception
Options
Original feeder
DP-7100 document processor with automatic reverse function (A6R-A3, capacity: 140 sheet A4, paper weight 35-160 g/m²), DP-7120 document processor with automatic reverse function (A5R-A3, capacity: 50 sheet A4, paper weight 45-160 g/m²), DP-7110 document processor with simultaneous duplex scanning (A6R-A3, capacity: 270 sheet A4, paper weight 35-220 g/m²), DP-7130 document processor with simultaneous duplex scanning and ultrasonic sensor for multi-feed detection (A6R-A3, capacity: 270 sheet A4, paper weight 35-220 g/m²)
Platen cover
Platen cover type E (if document processor is not installed)
Job separator
JS-7100: 100 sheet
Paper feed
PF-7100 (2 x 500 sheet universal cassettes [A5R-SRA3]), PF-7110 (2 x 1,500 sheet large capacity cassette [A4]), PF-7120 (3,000 sheet large capacity tray [A4], side deck)
Other options
Scan extension kit (A), Internet fax kit (A), Card authentication kit (B), Keyboard holder 10, Banner guide 10, UG-33 ThinPrint® kit, UG-34 Emulation option kit, IB-50 Gigabit Ethernet card, IB-51 WLAN card, IB-35 WLAN card, DT-730 (B) Document tray, NK-7120 Numeric Keyboard (10 keys), cabinet no. 76, HD-12 (320 GB HDD**)
