Kyocera FS-3820

////Kyocera FS-3820

Kyocera FS-3820

Manufacturer : Kyocera

Model : FS 3820

Printer Type : Workgroup printer – laser – monochrome
For Enquiry
Categories: , ,

Description

SPECS

GENERAL

  • Printer Type
    Workgroup printer – laser – monochrome
  • Manufacturer
    Kyocera

POWER DEVICE

  • Type
    power supply
  • Nominal Voltage  AC 230 V
  • Frequency Required  50/60 Hz
  • Power Consumption Operational  425 Watt
  • Form Factor internal

PRINTER

  • Technology  laser
  • Print Speed
    Up to 28 ppm – A4 (8.25 in x 11.7 in)
  • Built-in Devices
    status LCD
  • Connectivity Technology
    wired
  • Interface
    Parallel, USB, LAN
  • Image Enhancement Technology
    Kyocera Image Refinement
  • PostScript Support
    standard
  • Language Simulation
    Diablo 630, EPSON LQ, IBM X24E, KPDL3, PCL 6, PDF, PRESCRIBE IIe, PostScript 3
  • Fonts Included
    45 x barcode
    80 x scalable
  • Printer Features
    optional duplex
  • Type
    workgroup printer
  • Max H-Document Size
    8.5 m
  • Max V-Document Size
    14 in
  • Media Type
    business cards, envelopes, labels, plain paper, transparencies
  • Media Sizes
    8.5 in x 11.7 in, A4 (8.25 in x 11.7 in), A5 (5.83 in x 8.25 in), B5 (6.93 in x 9.83 in), Legal (8.5 in x 14 in), Letter A Size (8.5 in x 11 in)
  • Min Media Weight
    60 g/m²
  • Max Media Weight
    200 g/m²
  • Total Media Capacity
    600 sheets

POWER

  • Power Consumption Stand by / Sleep
    18 Watt
  • Frequency Required
    50/60 Hz
  • Power Consumption Operational
    425 Watt

MISCELLANEOUS

  • Microsoft Certifications
    Compatible with Windows 7
  • Consumables Included
    1 x toner cartridge (black) – up to 20000 pages

PROCESSOR

  • Processor
    Motorola PowerPC 750CXe 300 MHz
  • Type
    PowerPC 750CXe
  • Manufacturer
    Motorola
  • Clock Speed
    300 MHz

NETWORKING

  • Networking
    Print server
  • Network / Transport Protocol
    AppleTalk, IPX/SPX, NetBEUI/NetBIOS, TCP/IP
  • Data Link Protocol
    Ethernet, Fast Ethernet
  • Connectivity Technology
    wired

RAM

  • Max Supported Size
    320 MB
  • Slots Qty
    1
  • Empty Slots
    1

MANUFACTURER WARRANTY

  • Service & Support
    Limited warranty – 1 year
    Limited warranty – drum – 3 years

PRINTING

  • Max Resolution B/W
    1200 dpi
  • Max Printing Speed B/W (ppm)
    28 ppm

CARD READER

  • Type
    card reader
  • Supported Flash Memory Cards
    CompactFlash Card

MEDIA HANDLING

  • Max Media Size (Custom)
    8.5 in x 14 in
  • Media Weight
    60 g/m² – 200 g/m²
  • Media Type
    Envelopes, transparencies, labels, plain paper, business cards
  • Total Media Capacity
    600 sheets
  • Media Sizes
    Letter A Size (8.5 in x 11 in), Legal (8.5 in x 14 in), A4 (8.25 in x 11.7 in), A5 (5.83 in x 8.25 in), B5 (6.93 in x 9.83 in), 8.5 in x 11.7 in

SYSTEM REQUIREMENTS

  • OS Required
    Microsoft Windows 2000, Microsoft Windows Millennium Edition, Microsoft Windows XP

DUTY CYCLE

  • Monthly Duty Cycle (max)
    125000 pages
  • Cartridge / Printhead Duty Cycle
    20000
  • Cartridge / Printhead Included Qty
    1

COPIER

  • Copier Type
    none

ENVIRONMENTAL PARAMETERS

  • Sound Emission (Idle)
    33 dBA
  • Sound Emission (Operating)
    55 dBA

DOCUMENT & MEDIA HANDLING

  • Media Type Class
    envelopes, film / transparencies, other, plain paper
  • Media Size Class
    A4/Legal

HEADER

  • Brand
    Kyocera
  • Product Line
    Kyocera FS
  • Model
    3820N
  • Packaged Quantity
    1
  • Compatibility
    Mac, PC, Unix

INTERFACE REQUIRED

  • Connector Type
    4 pin USB Type B, RJ-45
  • Type
    LAN, USB 2.0, parallel
  • Total Qty
    1

OFFICE MACHINE

  • Type
    printer
  • Functions
    printer
  • Monthly Duty Cycle Range (Printer Class)
    100,000 pages and more
  • Monthly Duty Cycle (max)
    125000 pages
  • Printing Technology
    laser
  • Printing Output Type
    monochrome

DIMENSIONS & WEIGHT

  • Width
    13.6 in
  • Depth
    15.4 in
  • Height
    11.8 in
  • Weight
    28.66 lbs

EXPANSION BAYS

  • Type
    internal
  • Total Qty
    1
  • Free Qty
    1

SLOT REQUIRED

  • Type
    none

CONSUMABLES INCLUDED

  • Color
    black
  • Included Qty
    1

SOFTWARE

  • Type
    Drivers & Utilities

PRINTER OUTPUT

  • Max Speed
    28 ppm
  • Media Size
    A4 (8.25 in x 11.7 in)

PRINTER MEDIA

  • Media Load Type
    automatic
  • Media Feeder Qty
    1
  • Media Feeder Max Format
    Legal (8.5 in x 14 in)
  • Min Media Weight
    60 g/m²
  • Max Media Weight
    105 g/m², 200 g/m²
  • Media Feeder Capacity
    100 sheets, 500 sheets

PRINTER FONTS

  • Font Included Type
    barcode, scalable
  • Fonts Included Qty
    45, 80

PC CONNECTIVITY

  • Interface
    LAN, USB, parallel

SERVICE & SUPPORT

  • Type
    1 year warranty

SERVICE & SUPPORT DETAILS

  • Type
    limited warranty
  • Full Contract Period
    1 year, 3 years
  • Component
    drum

GENERAL

  • Manufacturer
    Kyocera
DV-67 (Developer Unit) 2FP93020
DK-67 (Drum Unit) 2FP93010
FK-67 (Fuser Unit) 2FP93060
FS-67 (Feed Unit) 2FP93050
Ozone Filter 2FP02070
Ozone Filter B 2FP02000
Roller M/P Assembly 2CL16130
Retard Assembly MK 2BR68570
